IMAGE SENSOR
Type : 36 x 24 mm CMOS
Effective Pixels : Approx. 18.10 megapixels
Total Pixels : Approx. 19.3 megapixels
Aspect Ratio : '3.2
Low-Pass Filter: Built-in/Fixed with fluorine coating
Sensor Cleaning : EOS integrated cleaning system
Colour Filter Type : Primary Colour
IMAGE PROCESSOR
Type : Dual "DIGIC 5+"
LENS
Lens Mount : EF (excludes EF-S lenses)
Focal Length : Equivalent to 1.0x the focal length of the lens
FOCUSING
Type : TTL-CT-SIR with a dedicated CMOS sensor
AF System/ Points : 61 Point / 41 f/4 cross-type AF points inc 5 dual cross type at f/2.8
The number of cross-type AF points will differ depending on the lens.
AF Working Range: EV -2 - 18 (at 23°C & ISO100)
AF Modes : One Shot, AI Servo
Selected AF Point Display : Superimposed in viewfinder
Predictive AF : Yes, up to 8m
AF Lock : Locked when shutter button is pressed half way in One Shot AF mode or AF-ON button is pressed.
AF Assist Beam : Emitted by optional dedicated Speedlite
Manual Focus : Selected on lens, default in Live View Mode
LCD MONITOR
Type : 8.11cm (3.2") Clear View II TFT, approx. 1040K dots
Coverage : Approx. 100%
Viewing Angle (Horizontally/Vertically) : Approx. 170°
Coating : Anti-reflection and Solid Structure
Brightness Adjustment: Adjustable to one of seven levels
Display Options : (1) Quick Control Screen, (2) Camera settings, (3) Dual Axis Electronic Level
Body Materials : Magnesium Alloy body covers
Operating Environment : 0 – 45 °C, 85% or less humidity
Dimensions (WxHxD) : 158 x 163.6x 82.7mm
Weight (Body Only) : Approx. 1340g
