Type : Console (Reader/Printer separated)
Maximum Original Size : A3
Copy Sizes : Cassette 1.2: A4, Cassette 3.4: A5R-SRA3 (320 x 450 mm), 13"x19"(330 x 483 mm)
Free size 139.7 x 182 mm to 330.2 x 487.7 mm
Stack Bypass: A5R- SRA3 (320 x 450 mm), 13"x19" (330 x 483 mm)
Free size 100 x 148 mm to 330.2 x 487.7 mm
Envelopes (DL, ISO-B5, ISO-C5)
Resolution : Reading: 600 dpi x 600 dpi, Copying: 600 dpi x 600 dpi, Printing: 1200 dpi x 1200 dpi (Text/Line only), 256 Gradations
Copy/Print Speed (A4, 80 gsm) : iR ADV C9070S PRO: 70 ppm (BW/Colour), iR ADV C9060S PRO: 60 ppm (BW/Colour)
First copy out time/first print out time : Black and white: 15 sec (FCOT), 8 sec (FPOT)
Full colour: 15 sec (FCOT), 8 sec (FPOT)
Warm-Up Time : iR ADV C9070S PRO: 6 minutes, iR ADV C9060S PRO: 5 minutes
Multiple Copies/Prints : 1 to 9999 sheets
Duplexing : Standard automatic stackless
Paper weights: Cassette: 52 to 220 gsm, Stack Bypass: 52 to 300 gsm, Duplex: 52 to 220 gsm
Paper Capacity Standard: 1,100 sheets x 2 cassettes (80 gsm), 550 sheets x 2 cassettes (80 gsm), Stack Bypass: 100 sheets (80 gsm)
Paper deck: 3,500 sheets, Multi-drawer Paper Deck: 6,000 sheets
Total capacity: 9,300 sheets (A4) 7,100 sheets (A3)
Memory : 2.5 GB
Hard Disk Drive : 80 GB
Interface : Ethernet (1000BaseT/100Base-TX/10Base-T)
Power Supply : 220-240V AC, 50/60Hz
Power Consumption : 2.68Kw
Dimensions (W x D x H) : (W) 1120 mm x (H )1400 mm x (D) 932 mm (with upright control panel in most left position)
(W) 1120 mm x (H) 1650 mm x (D) 932 mm (including operator attention light
(W)1275 mm x (H) 1400 mm x (D) 932 mm (with upright control panel in most right position)
Weight: Approx. 305 kg (with 1PDS, Upright Control Panel, PRISMAsync Server)
