Technology
Projection System : 3LCD Technology, RGB liquid crystal shutter
LCD Panel : 0.63 inch with MLA (D8)
Color Light Output : 5,000 lumen - 3,470 lumen (economy)
White Light Output : 5,000 lumen - 3,470 lumen (economy)
Resolution : XGA, 1024 x 768, 4:3
Aspect Ratio - 4:3
Contrast Ratio - 3,000 : 1
Lamp : 245 W, 2,500 h durability, 4,000 h durability (economy mode)
Keystone Correction : Auto vertical: ± 30 °, Manual horizontal ± 30 °
Video Processing : 10 Bits
Optical
Projection Ratio : 1.38 - 2.24:1
Zoom : Manual, Factor: 1 - 1.6
Projection Lens Zoom Ratio : 1 - 1.6 : 1
Lens : Optical
Projection Size :30 inches - 300 inches
Projection Distance Wide : 0.8 m - 8.4 m (60 inch screen)
Projection Distance Tele : 1.4 m - 13.9 m (60 inch screen)
Projection Lens F Number : 1.51 - 1.99
Focal Distance :18,000 mm - 29,000 mm
Focus : Manual
Offset - 8.6 : 1
General
Energy Use : 337 W, 250 W (economy), 0.44 W (standby)
Supply Voltage : AC 100 V - 240 V,50 Hz - 60 Hz
Product dimensions : 377 x 271 x 108 mm (Width x Depth x Height)
Product weight : 3.8 kg
Noise Level : Normal: 37 dB (A) - Economy: 29 dB (A)
Temperature : Operation 5° C - 35° C, Storage -10° C - 60° C
Humidity : Operation 20% - 80%, Storage 10% - 90%
Included Software : EasyMP Monitor, EasyMP Multi PC Projection, EasyMP Network Projection, EasyMP Slide Converter
Options : Air filter ELPAF38
Sound Pressure : Operation: 37 dB (A)-standby: 29 dB (A)
Loudspeaker : 10 W
