Technology
Projection System : 3LCD Technology, RGB liquid crystal shutter
LCD Panel : 1.06 inch with MLA (D8)
Color Light Output : 10,000 lumen - 7,600 lumen (economy)
White Light Output : 10,000 lumen - 7,600 lumen (economy)
Resolution : XGA, 1024 x 768, 4:3
Contrast Ratio - 5,000 : 1
Lamp : 340 W, 2,500 h durability, 3,500 h durability (economy mode)
Keystone Correction : Manual vertical: ± 30 °, Manual horizontal ± 20 °
Video Processing : 100 Bits
Optical
Projection Ratio : 1.63 - 2.65:1
Zoom : Motorized, Factor: 1 - 1.61
Projection Lens Zoom Ratio : 1 - 1.61 : 1
Lens Shift : Motorized - Vertical ± 56 %, horizontal ± 6 %
Projection Size : 60 inches - 500 inches
Projection Distance Wide : 1.9 m - 16.8 m
Projection Distance Tele : 3.2 m - 27.2 m
Projection Lens F Number : 1.65 - 2.51
Focal Distance : 36,000 mm - 57,000 mm
Focus : Motorized
Advanced Features
Security : Kensington lock
Features : DeepBlack technology, Epson Cinema Filter, Freeze image, Instant on/off, Network administration, Quick Corner, Reduced video noise, Six axis color control, Split-Screen-Function
Video Color Modes : Dynamic, sRGB, Theatre
General
Energy Use : 950 W, 790 W (economy), 0.5 W (standby)
Supply Voltage : AC 100 V - 240 V,50 Hz - 60 Hz
Product dimensions : 534 x 734 x 167 mm (Width x Depth x Height)
Product weight : 22 kg
Noise Level : Normal: 40 dB (A) - Economy: 35 dB (A)
Temperature : Storage -10° C - 60° C
Humidity : Operation 20% - 80%, Storage 10% - 90%
Included Software : EasyMP Monitor, EasyMP Multi PC Projection, EasyMP Network Projection
Sound Pressure : Operation: 40 dB (A)-standby: 35 dB (A)
